A wiring diagram is a simplified conventional pictorial representation of an electric circuit. Connecting a releasing device to the fcm 1 rel.
Notifier Fcm 1 Wiring Diagram General Wiring Diagram
Fcm 1 rel wiring diagram. When using the fcm 1 rel for class b applications remove jumper j1 and discard. The fcm 1 rel releasing control module uses a redundant protocol. Maximum slc current draw. 65 ma led on temperature range. Fcm 1 rel wiring diagram wiring diagram is a simplified customary pictorial representation of an electrical circuit. 16112018 16112018 3 comments on notifier fcm 1 wiring diagram.
Releasing applications c limited energy cable cannot be used to wire a. The module must be armed with a pair of signals in order to activate. Maximum slc current draw. Notifier nfs manual online. Secure module to electrical box supplied by installer as shown in figure 2. The fcm 1 has two pairs of output termination points available for fault tolerant wiring and a panel controlled led indicator.
Compatibility requirements to ensure proper operation this module shall be connected to a. This module can be used to replace a cmx 2 mod ule that has been configured for supervised wiring operation. Install module wiring in accordance with the job drawings and appropriate wiring diagrams. Control module barrier required by ul for sepa rating power limited and non power limited wiring in the same junction box as fcm 1 rel. It reveals the parts of the circuit as streamlined forms and the power as well as signal links in between the tools. 15 to 32 vdc.
Notifier nfse manual online. 5 for frm 1 general fcm 1 control module the fcm 1 addressable control module provides notifier intelligent control pan els a circuit for notification appliances horns strobes speak ers etc or to monitor a telephone circuit. Control module barrier required by ul for sepa rating power limited and non power limited wiring in the same junction box as fcm 1 rel. Releasing control module smb500. It will then enter a 3 second window awaiting a pair of confirmation signals. Variety of notifier fcm 1 wiring diagram.
It shows the components of the circuit as simplified shapes and the gift and signal contacts amongst the devices. If no confirmation is received the module will automatically reset. Set the address on the module per job drawings. 4675 h x 4275 w x 14 d mounts to a 4 square by 218 deep box specifications for frm 1. Notifier fcm 1 wiring diagram. 32f to 120f 0c to 49c dimensions.
15 to 32 vdc. Connecting a releasing device to a fcm 1 module connecting an. Dn 6724 040504 page 1 of 4 fcm 1 module see wiring diagram fig.
