Gsmv4g wiring diagram. How to wire the gsmv4g cellular communicator to the honeywell vista 20p wired alarm system. If not see pages 13 15. Nal wiring is complete. Distance from control panel 170 ft 52m 270 ft 82m minimum wire gauge 18 16. See pages 10 17 for detailed wiring guidelines mcr32387 mcr32389a r c y y2 g w o b w2 aux1 w3 aux2 a l a. View and download honeywell gsmv4g quick installation manual online.
Power connections and options. Use the four conductor wire to connect terminals 3 through 6 on the gsmv4g to terminals 4 through 7 on the vista 20p. Gsmv4g cell phone pdf manual download. Install and wire as above if using eim. Intellipathtm series 4g gsm communicator auto selects optimum gsm path 2g 3g or 4g gsmv4g gsmvcn4g supports two way voice installation and setup guide 800 11119 112 rev. The 7847i has a very low current draw 75 ma maximum.
Tab optional wiring knockouts tab igsmv4g 001 v0. Wiring the fault relay gsmv4ggsmvcn4g installation and setup guide wiring the zone 1 input for a ground v trigger zones should use eol resistors and be pro grammed as v inverted or v inverted operation such that a cut line results in an alarm. Refer to the diagram on page 5 and to the wiring diagram on the inside of the back cover of this man ual for wiring and component identification. If you are looking for the best rates in business or commercial alarm monitoring automation and or. When all wiring has been completed including the internet cable if used attach the case front. Alarmnet 360 online help guide.
Terminals 4 7 on the vista 20p are the ecp terminals and will already have wires landed to them as all alarm keypads wireless receivers and four wire alarm sensors use these terminals. Mount the thermostat and wire to c and r terminals of the equipment interface module eim or to a separate 24 volt transformer not provided. Distance from control panel 75 ft 23m 120 ft 37m minimum wire gauge 22 20. This is because it. While the igsmv4g is the product featured the wiring process is also the same for the honeywell 7847i with one exception. Remove knockouts from cabinet to accommodate the power input wires and wiring to the fire panel.
Then mount the cabinet securely to the wall using 4 screws or bolts.
