Brakerite wiring diagram. Weather pack connectors are connected in line to the existing brakerite harness near the actuator. Page 7 of 16 a titan company 2345 east market street des moines ia 50317 phone. When making connections to the trailers wiring harness the desired. 800 usa bear or 800 872 2327 fax. The brakerite ii has no ecb and has a three wire cable with a female weather pack plug therefore it requires a control module. K58 036 01 wiring diagram for brakerite plug and play actuators.
This particular actuator is designed for use with hydraulic drum brakes and features 1000 psi of hydraulic pressure. Figure 2 brakerite ii sd wiring diagram installation mounting location of any brakerite model is at discretion of installer however accessibility for service protection from damage and ability to minimize length while protecting brake lines are factors to be considered. Approximate physical envelope for power unit is 6 front to back 7 14. Brakerite wires and wire connections the wires on the brakerite system wiring harness are approximately 2 metres long see page 9 to allow for flexibility when mounting the unit however extensions may be required to connect unit to the trailers electrical wiring. Rea aay sitc layard trailer lu ro to veicle cotroller typically lue 1 olt 0 ap circuit ro to eicle roud ro to eicle reaaway attery 1 olt ap hour iiu lue lack hite. Figure 1 brakerite ehb wiring diagram figure 2 brakerite ii sd wiring diagram.
Installer per the wiring diagram. With the brakerite ii either the sd or rf control module is used both systems described below. I have attached the wiring diagram for the titan brakerite ehb electric hydraulic actuator t4822500 that you referenced.
