221 single innovate device relay wiring instructions 3 sensor placement optimum bung placement will vary from application to application but using the guideline below will ensure the longest sensor life with the most accurate readings. Use a 470 ohm 14watt resistor in between the analog output of the lc 1 and the o2 input of the megasquirt.
Innovate Motorsports G2 G4 G5 Air Fuel Gauge Manual Four
Innovate wideband wiring diagram. Upon first glance it appears similar to a conventional sensor and gauge combination designed to give the driver specific information. For any lc 1 purchased after june2006 that should be all you need to be concerned with when wiring it up. How to tint a back window duration. 2 1 overview the lc 1 is a stand alone wideband controller used to measure the airfuel ratio afr or lambda. Using a bung is the preferred method for mounting the oxygen sensor in all applications. Connect the db gauges white wire to the lc 1s brown wire.
The gauge is setup to work with an analog output configuration of 0v 735 af and 5v 2239 af. Connect the db gauges white wire to the lc 2s yellow wire. Innovate lc2 wideband o2 sensor install with ecmlink v3 duration. The bung extender is recommended for situations where airflow is restricted or the encountered heat is higher than a heat sink can handle. Innovate lc2 wideband o2 sensor install with ecmlink v3. 211 single innovate device relay wiring instructions 22 mounting and routing the mtx l gauge fits in any standard 2 116 52mm gauge pod.
Innovate motorsports heat sink bung extender hbx 1. Consult your factory service manual for wiring diagrams andor use the common sense methods i demonstrated here the illumination. How to fabricate a copper heat sink use a 4 x 4 10cm x 10 cm sheet of copper sheet metal 14ga 15mm thick. The lc 1 is a stand alone wideband controller used to measure the airfuel ratio afr or lambda for an engine. For gasoline driven engines the theoretically optimal air fuel ratio is 147 pounds of air for every pound of fuel. Route the sensor cable.
At this ratio theoretically all available oxygen in the air combines with all available fuel. Mounting of the gauge should be done in such a manner that the cables are not being forcefully pulled and strained from the gauge itself. Connect the db gauges white wire the lm 2s. Ralph van pelt 474775 views. So youll wire the analog output from the lc 1 to one side of the. Single innovate device relay wiring instructions 3 sensor placement optimum bung placement will vary from application to application but using the guideline below will ensure the longest sensor life with the most accurate readings.
Drill a hole in the. It uses a bosch lsu 49 wideband o2 sensor and is compatible with several different fuels. For example the innovate mtx l plus is an advanced stand alone wideband air fuel controller and digital readout gauge. If you purchased your lc 1 prior to july 2006.
