Switches are actuated when a flow of 10 gpm 38 lpm or more occurs. Carefully place a screwdriver on the edge of the knockout and sharply apply a force sufficient to dislodge the knockout plug.
Bep Wiring Diagram Bep Vsr Wiring Question The Hull Truth
Potter vsr wiring diagram. Potter electric signal company llc st. Break out thin section of cover when wiring both switches from one. Potter vsr flow switch wiring diagram. 866 956 0988 customer service. Louis mo phone. Remove the tamper resistant screw with the special key provided.
It is ul the switches are actuated when a flow of 10 gpm 38 lpm or more occurs. Louis mo tech support. Cover tamper switch kit stock no. 2 dn50 vsr 2 1144402 2 12 dn65 vsr 2 12 1144425 3 dn80 vsr 3 1144403 vsr 3 12 1144435 4 dn100 vsr 4 1144404 5 vsr 5 1144405 6 dn150 vsr 6 1144406 8 dn200 vsr 8 1144408 specificationssubject to change without notice. The model vsr is a vane type waterflow switch with non corrosive insert for use on wet sprinkler systems. Run wires through an approved conduit connector and affix the connector to the device.
Potter vsr flow switch wiring diagram 19082018 19082018 5 comments on potter vsr flow switch wiring diagram potter electric signal company llc st. How to wire a potter vsr at autotest flow switch. Chris craft 266917. This video demonstrates how to properly wire a vsr at autotest flow switch. The model vsr is a vane type waterflow switch for use on wet sprinkler systems. Detailed guide on.
Canada the model vsr is a vane type waterflow switch for use on wet sprinkler systems. Potter vsr flow switch wiring diagram kaijin musen jp 112 htmltranslate this page 1 3 5 tel 03 3251 0025 fax 03 3256 3328 email web s. Schedules 10 through 40 sizes 2 thru 8 50 mm thru 200 mm and schedule 5 sizes 2 thru 6. Vsr s eu vane tpe aterfo aar st t retar spt trea for sa ppe stock no. The center position is the normal installation position. The unit may also be used as a sectional waterflow detector on large systems.
1144444 the model vsr s eu is a vane type waterflow switch for use on wet sprinkler systems that use 25mm 1 32mm 1¼ 38mm 1½ or 50mm 2 pipe size. It is ul listed and fm approved for use on steel pipe. How to wire a doorbell diy live demo and wiring diagram duration.
