Ptz wiring diagram. You may decide to go with a traditional analog system hd sdi hd cvi or even an ip network based security products. Speeddome camera dome installation and service manual 8000 1715 01 rev. The following wiring diagram shows that how to connect an analog ptz camera to the dvr and joystick ptz controller. A basic knowledge of electrical wiring and low voltage electrical connections. As far as cameras power ptz data and wiring is concerned theyre. The following diagram shows an example ptz camera system installation using the ck 983321 ptz camera controller the idvr pro cctv camera dvr and 3 pan tilt zoom cameras.
This is how to wire a ptz to a joystick for rs communication. This 182 power cable can be used to for the rs 485 communication between the joystick and cameras. The rs configuration on the ptz camera and the control unit must. Rs uses 2 wires to send and receive data to. If you use a pair of video power data ptz baluns you can wire the camera to your dvr using a cost effective cat 6 network cable. The bnc cables are used for video signal transmission while the rs 485 cables are used to control the camera movement and rotation by connecting it to the joystick ptz controller or dvr system.
Ptz camera system installation. Almost every dvr has the ability to control a multitude of devices using the rs protocol. The rs configuration on. There are 2 rs485 leads that also need to be wired to the dvr or ptz controller. Ptz camera utc wiring diagram to dvr. Ptz controller wiring diagram collection variety of ptz controller wiring diagram.
It shows the components of the circuit as simplified shapes and also the power and signal connections in between the gadgets. A wlg 1 o97. 1 input power 12vdc or 24vac 2 control rs 485 3 output video coax cable typically 1vdc p p. Simple wiring diagram a quick review of a ptz cameras wiring figure 2 concludes there are three 3 pairs of wires to be concerned about. One thing all of these options have in common is you will probably have to run some sort wire to the cameras. A basic knowledge of electrical wiring and low voltage electrical connections.
A wiring diagram is a streamlined conventional photographic representation of an electric circuit. Cctv installation and wiring options. Today there are a lot of options when it comes to choosing a quality cctv security system. Addition is that it has an extra wire pair known as the rs communication wires which sends communication signals from your.
