Setras model 267 is setras most highly configurable multirange low differential pressure transducer. The model 264 is a two wire loop powered 4 to 20ma current output unit and delivers rated current into any external load of 0 to 800 ohms.
Setra S Multi Sense 231 Model Pressure Transducer Youtube
Setra 264 wiring diagram. Enclose any required mating electrical connectors and wiring diagrams. It delivers accuracies of 025 05 and 1 fs and pressure ranges from 01 wc. The circuit see diagram 2. The current flows into the terminal and returns back to the power supply through the terminal see diagram 4. The setra sensor the core technology of the 264 is the all stainless steel capacitive sensing element. Allow approximately 3 weeks after receipt at setra for the repair and return of the unit.
The model 264 is a two wire loop powered 4 to 20ma current output unit and delivers rated current into any external load of 0 to 800 ohms. The 264 voltage output can operate from 9 30 vdc. Convenient installation the 264s base mount allows the sensor to be installed anywhere. These terminals have the designation com exc and out see diagram 1. With millions of sensors installed world wide setras 264 is the standard for low differential pressure measurement in hvac building automation. The current flows into the terminal and returns back to the power supply through the terminal see diagram 4.
The setra sensor the core technology of the 264 is the all stainless steel capacitive sensing element. Its 007 fs accuracy is calibrated using the end point method which improves linearity when compared to competitive transducers which use the best fit straight line method of calibration. Up to 100 wc. Convenient installation the 264s base mount allows the sensor to be installed anywhere. Have the designation of and see diagram 3. The 264 very low differential pressure.
The power supply and signal references are commoned on. The power supply and signal references are commoned on the circuit see diagram 2. The dpt264 voltage output can operate from 9 30 vdc excitation. Setra designs and manufactures all of their sensing elements resulting in full control over the process and quality of every single sensor. These terminals have the designation of and see diagram 3. These terminals have the designation com exc and out see diagram 1.
The 264 has a 0 5. Setra designs and manufactures all of their sensing elements resulting in full control over the process and quality of every single sensor. Non warranty repairs will not be made without customer approval and a purchase order to cover repair charges. Setra systems 264 pressure transducers sense differential or gauge static pres. Setras model asl is the highest accuracy transducer for measuring low differential pressure in the accusense product line. The model dpt264 voltage output is a 3 wire circuit with three terminals available for wiring.
The dpt264 has a 0 5 vdc output. The 267 is housed in a robust nema 4 rated enclosure and has an optional static pressure probe reducing installation and material costs.
