Shaver socket wiring diagram. An accessory embodying a shaver transformer and one or more socket outlets. There are two types of shaver sockets available those with transformers and those without. Installing a shaver socket. The transformers in shaver sockets are not to provide low voltages although they are of course used to produce 110v. Steve contacted us with this valid point which we thought would be useful to share with you. The term shaver supply unit means.
The fan need to be of a low voltage type the isolator and transformer are fitted outside the bathroom the isolator is normally placed above the door and often the transformer in the loft. Both of these items usually run of the lighting circuit. What they probably meant to do was put the fan and the shaver socket on the isolator so should you need to isolate the fan or the socket you could do so. When wiring ensure to link the earth neutral and live wires after connecting the wires in your shaver socket to their corresponding terminals. Shaver sockets can be install a shaver socket either by connecting to a ring main with a junction box see adding a spur to a ring circuit from a junction box or from an earthed lighting socket. The spur from the ring main must be fitted with a 3amp fused connection unit before connecting to the shaver socket see fitting a fused connection.
A shaver socket outlet with a transformer is called a shaver supply unit. Only the transformer socket can be fitted in the bathroom because the it isolates the supply from the mains making it safer and suitable for bathroom use. The subtle design will blend with any décor suitable for domestic or commercial installations. A shaver supply unit complying with bs en 61558 2 5 may be installed in zone 2 of a location containing a bath or shower regulation 7015123 refers. However the fan should only switch on when you turn the light on and will usually have a run on timer that switches the fan off a certain time after you switch the light off. The shaver socket does not need an isolator.
Wiring diagram for shaver socket. The transformer is there to provide electrical isolation from the mains older. To assist with the correct installation please consult the appropriate wiring diagram on this leaflet. This is a vital part of the process so if you need more information on this then ensure you check the wiring diagram carefully and follow the colour coding techniques.
