1 removing the front cover 2 mounting control centre onto wall 3 wiring cables for power thermostats auxiliary relays and actuators 4 fixing the cables and closing the cover before you commence wiring make sure you identify which h box wiring centre model you have. Underfloor heating wiring diagrams.
B64 Wunda Underfloor Heating Wiring Diagram Wiring Library
Wunda wiring centre diagram. Wiring diagram 1 removing the front cover 2 mounting control centre onto wall 3 wiring cables for power thermostats auxiliary relays and actuators 4 fixing the cables and closing the cover manifold pump max 3 actuators can be connected to one channel boiler zone valve switch voltage free or with link 230v. View our wide range or wiring diagrams and wiring options download pdfs of each diagram here. Once you know which wiring type is right for the system and the thermostat youre installing you can head to our resources section where you can choose between uh2 uh1 uh1 w uh3 uh8 rf wiring centres as well as view a trades layout and single zone wiring diagram if needed. Heating controls wiring guide issue 17 v4073a y plan how a mid position valve operates within a y plan heating. 1 x potential free relay output right hand1 x independent relay output 230vac 3a two relays will be engaged whenever one or more thermostats call for heating. Schematic system boiler with hot water cylinder radiators ufh installation guide wiring plumbing e09 the brand you can trust 0800 5420 816 wwwwundafloorheatingcouk.
All electrical work must be completed by a qualified trades person. Home professional zone resource centre wiring diagrams. Wiring centre h box 12 technical data. Wiring centre h box 12 v12 e07 the brand you can trust 0800 5420 816thermostats stop heating activity wwwwundatradecouk 11 wiring centre h box 12 l n l1 l1 n transformer ground. If you would like a get a free quote contact us 08002321501. Wunda only provides pipe which is 100 leak proof.
Contains all the essential wiring diagrams across our range of heating controls. Wunda section a 1a. View our wide range or wiring diagrams and wiring options download pdfs of each diagram here. By using a 5 layered pipe comprised of an evoh barrier to prevent oxygen ingress and rusting the aluminium core as well as pert for superior flexibility were able to stand proudly by the lifetime guarantee we give the pipe we supply. Before you commence wiring make sure you identify which h box wiring centre model you have. Click the icon or the document title to download the pdf.
All electrical work must be completed by a qualied trades person. Wiring centre 2b typical wiring scheme for multi zone ufh with a combination boiler. If you would like a get a free quote contact us 08002321501. Supply voltage 230vac 5060hz outputage vol t 230vac 5060hz maxload 4a number of zone outputs 12 zones left hand.
