Connect the cable to the back of your cooker locate the terminal outlet box on the back of your appliance and unscrew the plate. I have an idea which is correct but want to be certain.
Page 10 Of Zanussi Oven Zdf867x User Guide Manualsonline Com
Zanussi cooker wiring diagram. Sorry for the newbie questionwould be grateful for some help in hardwiring a cooker zanussi zcv621mw with a double oventhe back terminal board looks like thisand the mains connection in the box looks like thisthe manual recommends the cable of 6mm2 and provides a scheme like this. My cable wire has live neurtal and earth. Zanussi oven wiring query to connect built in oven. If you accept anonymous cookies are used to improve our site and services. 3 with covers for 220v and 3 accessable for 240v. Third party content is also used.
Doesnt seem to be any obvious way to connect the 3 wires. The wires im connecting are from a dedicated cooker isolator but my issue is where to put them into the cooker. There are 6 large screw points. By garfield59 fri oct 21 2016 745 am. Can you give me the exact wiring connections for a zanussi zkc5030 electic cooker. Find your wiring diagram zanussi oven here for wiring diagram zanussi oven and you can print out.
Your connections on the cooker are l l n n n e please place c clips between 1 2 then between 3 4 and also 4 5 as shown on the manual. Main switch on programme selector 4. How to wire oven hob diversity on a cooker circuit wiring diagram duration. Search for wiring diagram zanussi oven here and subscribe to this site wiring diagram zanussi oven read more. The new one is a zanussi zob353031. 1st level pressure switch.
1 post page 1 of 1. Zanussi uses cookies and various tracking technologies for site optimization as well as promotional and marketing purposes. Ive been asked to fit a new built in oven in a friends kitchen to replace her old broken one. Then place your red wire into the connection for 2 place your black wire into the connection for 4. Some information may be shared securely with trusted partners. There are 6 connectors on the oven 3 at the top and 3 at the bottom.
Each of the 3 screws corresponds to the cooker wiring for ln e. Connect the live brown neutral blue and earth green yellow wires into their appropriate slots neutral goes to the left live to the right earth to the centre. How to remove a built in oven single or double duration.
