The 1761 net aic can be used as a point to point isolator or an rs 232 to an rs 485 isolator. Page 22 installation and wiring 1761 cbl ap00 and 1761 cbl pm02 cable 1761 cbl pm02 1761 cbl ap00 1761 cbl ap00 and 1761 cbl pm02 cable cable length connects external selection power switch from to aic supply setting interface required converter 1761 cbl ap00 45 cm slc 503 slc rs 232 8 pin external 177 in 504 or slc mini din 505.
Ab Advinterfaceconverter 1761 Net Aic User D498
1761 net aic wiring diagram. For users of 1769 sdn with micrologix 1500 controller we recommend migration to compactlogix 5370 l1 or l2 controllers. Overall usefulness completeness all necessary information is provided technical accuracy all provided information is correct 1 2 3. Publication 1761 in002b mu p fr juillet 2003 notice dinstallation section en français convertisseur dinterface évolué aic et interface devicenet dni références 1761 net aic et 1761 net dni spécifications description spécifications aic spécifications dni alimentation 24 v cc. I only know the wiring and then. The 1761 net aic is designed to provide compatibility with the slc processors and it comes with the ability to interconnect slc 500 501 502 and 503 processors. Cable diagram 4 1761 l16awa 1761 l32awa 1761 l20awa 5a 1761 l10bwa 1761 l16bwa 1761 l20bwa 5a 1761 l32bwa 1761 l10bwb 1761 l16bwb 1761 l20bwb 5a 1761 l32bwb 1761 l16bbb 1761 l32bbb 1761 l32aaa advanced interface converter 1761 net aic gp series cpu link cable diagram cables gp 1764 lsp rs 232c port on base unit rs 232c cable diagram 2.
Manuals and user guides for allen bradley 1761 net aic. Our company has an equipment barcode scanner which need to be connected with the ab plc dh485 interface. Communication cables for class 1 div environments environment classification communication cables class i division 2 hazardous environment 1761 cbl pm02 series c or later 1761 cbl hm02 series c or later 1761 cbl am00 series c or later. Please complete the sections below. 11 à 25 v cc. Requise 204 à 288 v cc.
All wiring must comply with nec. Articles 501 502 503 andor cec. I also tried connecting each hmis gnd or pin 1 of the rs232 to the com of the dh485. We recommend these replacement products. Cable wiring shown in the datasheets connects the com of the dh485 port of the 1747 net aic to the pin of the rs232 port of the hmi for dh485 configuration. We have 1 allen bradley 1761 net aic manual available for free pdf download.
Section 18 1j2 as appropriate. Date june 2006 part no. Where applicable rank the feature 1needs improvement 2satisfactory and 3outstanding. Our bulletin 1761 net aic 1761 net eni 1761 net eniw and 1769 sdn communication modules are discontinued and no longer available for sale. I am so sorry that i am a new beginner of the ab plc. Compliance to european union directives.
But our scanner only has the rs232 interface so that we need the 1761 net aic to convert the rs232 to dh485. I have a question about the 1761 net aic. Im thinking of testing with two panel view plus with the same wiring.
