Antenna rotor wiring diagram. The first is the power circuit which in all tenna rotors transmits the power that actuates the motor. Look in you instruction manual to see what wire size to use for longer runs. Antenna masts coaxial cable and rotator cable figure 2 figure 3 2. A owners manual pin 51563 10. Lower mast support antenna size is restricted to 75 square feet of wind surface area. Controller unit new features in the ham iv include an 8 pin.
The control unit must be placed inside the house or other protected location. Included in the rotor are. The rotor wire as shown. Stanoff antenna wire slack antenna lejowiae step 11 f ig. Remote control control remoto. Most rotor wire will be color coded.
The rotor unit which mounts on the mast below the antenna and the control box which is placed on or about the tv receiverthese are interconnected by a four or five conductor cable. Remove the bottom or access plate of the drive unit housing and attach the rotor wires. Facilitate mounting the ham iv rotator on top of a mast. The control unit mus be placed inside the house or other protected location. Control box installation s tep a. The theory of operation concerns two separate circuits.
Included in the shipping box are. The alliance tenna rotor consists of two units. The rotator unit must be wi red to the controlunit with an 8 wire cable. For runs up to 200ft you can use 22ga 3 conductor wire. Continue to use separate stand offs for anten na wire and rotor wire. Control unit rotator wire not included unidad de control el cable del rotor no está incluido unité de contrôle fil du rotor non inclus 3.
All channel master antenna rotors use 3 conductor rotor wire. The rotator unit must be wired to the control unit with an 8 wire cable.
