Contact your local bac representative if you do not have this diagram. Circuit electrical wiring enters the switch box.
Perceptiv Solution Preventive And Predictive Methods For
Bac vibration switch wiring diagram. In this illustration we will going to wire the vibration switch module this module is default off when external vibration force or a movement speed from the sensor a conductive pin will switch on change the electrical property of the sensor when the external force disappears the electrical property will open and turn to off. To order your vs2 series model use the diagram below. Reset the switch by depressing the reset plunger and start the machine. Since the switch comes from the factory with the slide switch in the nc position see wiring diagram for the slide switch location the light bulb should turn on immediately. To adjust setpoint when installed on the machine mount and wire the unit. Featuring wiring diagrams for single pole wall switches commonly used in the home.
Jumper terminals 1 and 3 together. 51 wiring to the vibration switch see terminal numbering legends below. Mechanical operation with multiple options for alarms and reset. Explanation of wiring diagram 1. Dated 0 995 after use straight snap switch arm no rollers. How to wire a single switch.
Use good installation practices that slope conduit away from the switch use drains non xp installations only and make. Unless proper drains andor poured seals are used conduit can allow moisture entry into the switch. Place jumper between opta9 terminals 3 and 5. Shock and vibration switch vs2 series. Guarantees year round reliable and safe operation. When the machine has reached full speed slowly turn the vibration setpoint adjustment counter clockwise until the switch tips.
The switch detects excessive fan drive vibration caused by fan icing or any mechanical fault. Confirm control wiring from the analog input device into the vfd per chapter 4 of the users manual see appendix d for wiring diagrams. If using a two wire 4 20ma temperature or pressure sensor. Switch wiring shows the power source power in starts at the switch box. Wire lead to opta9 terminal 12. Electronic switches are compatible with building management systems and for use on bac evapco marley and other non bac units.
Then turn the adjustment clockwise a small amount approx. Vcos electronic 110v60hz electric vibration cutout switch with remotelocal reset and delay. Refer also to the wiring diagrams of section 8. Connect a 25 watt light bulb to terminals 2 and 4. Vs2exr 24 models with date 0895 and before use old switch. Wire lead to opta9 terminal 4.
