Fuji electrics new frenic mini c2 series provides excellent performance for both single phase and three phase applications and is available in multiple configurations to support 18 hp up to 20 hp ac drives variable frequency drives vfd v hz vector drives. But an internal emc filter has been developed for the frenic mini series in compliance with the european.
Fuji Electric Frenic Mini Series Manuals Manualslib
Frenic mini wiring diagram. Quick start commission 21. And follow the instructions contained in the frenic mini instruction manual chapter 7 section 74 insulation test control circuit wiring length when using remote control limit the wiring length between the inverter and operator box to 656 ft 20 m or less and use twisted pair or shielded cable. Wiring length between inverter and motor. View online or download fuji electric frenic mini user manual instruction manual. Compliance with emc standards. With an expanded range of rated voltages the new frenic mini c2 strikes.
For single phase 100v input series dcr shall be connected to the point that is shown below. Fuji electric frenic mini pdf user manuals. Fuji frenic mini drive connection diagram 3 wire mode potentiometer start stop wiring hindi duration. Frenic mini may not be used for a life support system or other purposes directly related to the human safety. Fire or an accident could occur. Operation using the keypad 19 5.
Do not use it for single phase motors or for other purposes. 1112 considerations when using frenic mini in systems to be certified by ul and cul if you want to use the frenic mini series of inverters as a part of ul standards or csa standards cul certified certified product refer to the related guidelines described on page ix. Fuji electric motor wiring diagram wiring diagram database electrical starting guide frenic multi fuji electric instruction manual fuji electric corp of america fuji frenic mini drive connection diagram 3 wire mode potentiometer start stop wiring hindi motors applied products fuji electric global single phase motor wiring diagrams north. Genus controls 9735 views. When connecting a dc reactor dcr option remove the jumper bar from across the terminals p1 and p. Wiring 8 31 removing the terminal cover and the main circuit terminal block cover 8 32 wiring for main circuit terminals and grounding terminals 10 33 wiring for control circuit terminals 10 34 connection diagram 16 35 setting up the slide switches 17 4.
Frenic mini is designed to drive a three phase induction motor and three phase per manent magnet synchronous motor pmsm. Wiring for main circuit terminals and grounding terminals. Frenic mini c2 control wiring note 1. Moreover in former models a noise reducing emc filter was an optional external attachment. Connection diagram in operation by external signal inputs. The frenic mini series employs such noise reducing schemes as a structure that cuts off the transmission path for the fet of the control power supply.
