Hunter icc wiring diagram. All wire splice connections should be done using waterproof connectors. In this video i describe how to set and program a hunter icc. Controller hunter icc 800pl owners manual and installation instructions. It was sunset in 2011 to make way for the i core which offers innovative features like state of the art flow monitoring quick system overview access a factory installed smartport six language capability and a bold graphic display. I do not go over advanced features i will do that in a later video. The icc is hunters original commercial grade controller.
The controller can operate with either 120vac or 230vac power. Remove the screw and wiring compartment cover from the front of the transformer junction box. Icc controller has been replaced by the icc2 controller. A wiring diagram is a streamlined traditional pictorial representation of an electric circuit. Check field wiring and valve solenoid. Connecting to the hunter solar sync part srr scwh with a full 25 feet 76 meters of shielded cable.
Commercial irrigation controllers plastic cabinet international metal cabinet stainless steel cabinet plastic pedestal field satellite controllers for imms. It shows the parts of the circuit as simplified shapes as well as the power and signal links between the gadgets. Route valve wires through the conduit and attach conduit to one of the openings on the bottom of the cabinet. Turn ac power off at the source and verify that it is off. Supply wires must be 14awg 2 mm2 or larger. View and download hunter icc 800pl owners manual and installation instructions online.
Variety of hunter ceiling fan wiring schematic. Commercial irrigation controllers plastic cabinet international metal cabinet stainless steel cabinet plastic pedestal field satellite controllers for imms 45 pages. Press any button to clear err message. Connecting the controller to primary ac power should be done by a licensed electrician following all local codes. Commercial irrigation controllers owner s manual and installation instructions icc 800pl plastic cabinet icc 801pl plastic cabinet international. Display possible cause solutions display shows err with number short in field wiring or bad solenoid.
We have worked at thousands of home owners and. Icc 800pl controller pdf manual. Strip ½ 13 mm of insulation from ends of all wires. Display shows p err. Connecting to the hunter solar sync the solar sync is a sensor system that when connected to hunter pro c will automatically adjust your controller watering based upon solar sync sensor changes in local climate conditions.
