I believe the edfc motors are the same and just the controllers is whats different. For the accessory ive tapped into the ign fuse wire.
Tein Edfc Location Acurazine Acura Enthusiast Community
Tein edfc wiring diagram. Illumination now for the always on ive picked the passenger side power seat wire. This is the most important part and is sometimes easier with some help. The edfc motors are very low profile and sink pretty deep into the top of the struts. Extensibility one controller unit can control up to 8 motors with additional motor driver unit installed. Im not quite sure what to take for illumination and was wondering if you guys had better suggestions for the other two wires. Install the edfc motor to the top of the piston rod.
Edfc active offers lots of extra features including adjustable display color and g force display. Uses a stopper bracket to eliminate tangling of edfc wiring on strut type front suspensions. The edfc electronic damping force controller makes it possible for the driver to control the damping force at the touch of a button while in the drivers seat. The wires can be in the way so youll have to cable tie them down using your best judgment so they stay out of the way. In addition with optional gps kit installed vehicle speed altitude longitude latitude trip meter andor clock can be displayed. The tein edfc wiring requires.
Now turn the edfc motor 3 full rotations. Accessory power up 3. Always on power 2. 1 harness plug between edfc motor and edfc wiring harness. You can see on this male connector that the pin on the right has been pushed back not allowing a connection to be made. What you need to do is place the edfc motor shaft into the edfc hex bolt.
At this point the edfc motor should have started to thread onto the piston rod. This is accomplished by controlling stepping motors installed on each shock absorber. The terminals pins inside the plug can be pushed out slightly causing the connection to be lost.
